GTS Enterprise Features and Add-On Modules
Jump To:
Basic GTS Enterprise
Building upon the features and capabilities of the OpenGTS system, we add various other features from our commercial GTS Enterprise suite to create a customized GPS tracking/telematic solution to fit your specific requirements.
Our Basic GTS Enterprise includes the following additional features:
-
Additional web-interface support (source code included):
- User "Role" administration support.
- Custom StatusCode descriptions administration support.
- "System Administrator" account support providing the ability to create new accounts through the web-interface.
- "System Information" page which summarizes basic GTS system attributes
- A "Lite" version of the Event Notification Rules-Engine feature which provides the ability to send email notification on Geozone arrival/departure (minor custom coding/configuration necessary).
- GTS DB administration utility (binary) with user interface.
- Configuration Assistant utility (binary) to help with simple configuration changes (Linux platforms required).
-
Additional configured reports:
- Geozone Elapsed Time Report.
- Geozone/Driving Report.
- Trip Detail Report.
- Periodic Maintenence Report (requires vehicle, or GPS-based, odometer).
- Distance Traveled Summary Report (requires vehicle, or GPS-based, odometer).
- Temperature Monitoring Report (requires temperature sensors).
- Wireless Data Usage Report.
- Unassigned Devices Report (requires device communication server support).
- Additional documentation.
- Autostartup scripts (on reboot) for Fedora and CentOS.
- Web-service support for accessing the GTS database and querying report, mapping, and database information in XML format.
-
Included device communication server support:
- Boost Mobile Motorola i415 / i425 / i290 / i335 phone (OpenDMTP compliant)
- HP iPAQ hw6945 phone (OpenDMTP compliant)
- Windows XP (OpenDMTP compliant)
- Windows XP Embedded (OpenDMTP compliant)
- Windows Vista (OpenDMTP compliant)
- Windows CE/Mobile devices (OpenDMTP compliant)
- Linux embedded devices (OpenDMTP compliant)
- Sanav GC-101 TCP/UDP-mode (personal tracker) [purchase from ElectronGPS]
- Sanav GX-101 TCP/UDP-mode [purchase from ElectronGPS]
- Sanav CT-24 TCP/UDP-mode (personal tracker) [purchase from ElectronGPS]
- iCare G3300 (personal tracker)
- Device Communication Server support for "Unassigned Devices" to keep track of incoming communication from remote GPS tracking units that have not yet been assigned to an Account/Device.
- Free client GPS tracking software for the Motorola i290 Boost Mobile Phone. (Requires Boost Mobile service and coverage to utilize the i290 phone as a tracking device)
- Purchase includes 30 days of technical/configuration support. (Continued upgrade support, and remote installation, via "ssh", on selected Linux distributions also available for additional fee).
Event Notification Rules Engine
(see also the Feature Comparison chart below)
As a separately priced add-on to the above Basic GTS Enterprise, we can provide a full commercial version of our Event Notification Rules Engine which includes the following features:
- Event Notification Rules-Engine support module (binary) license, which can analyze incoming events and send email notification (or SMS messages with wireless service provider support) based on certain pre-defined criteria, such as arrive/depart, low-battery (provided the hardware supports low battery events), panic, digital-input changes, time-of-day, etc.
- The Event Notification Rules-Engine module can also be used for selecting specific icons to display on a map based on the specific type of event. Such as displaying a specific icon for "ignition on" events, etc.
- Additional web-interface for creating event rules.
- Documentation for creating and using event rules.
- Assistance in setting up various types of 'Rules'.
- Purchase includes 30 days of technical/configuration support. (Continued upgrade support also available for an additional fee).
Additional Remote Tracking Device Support
As separately priced add-ons to the above Basic GTS Enterprise, we can provide support for many devices from different GPS tracking/telematic hardware manufacturers. We can also implement support for other tracking devices if not already listed below.
The following is a partial list of our currently supported remote tracking/telematic devices available as separately priced binary add-on modules to the basic GTS Enterprise. (The price of the binary license depends on the specific device communication server chosen.)
-
Antx, Inc.
- Messenger (J1708/J1939/CanBus)
- Receive data via UDP
- UDP acknowledgments
- End-of-day events
- Actual vehicle odometer and fuel usage data, etc.
- Engine fault codes
- Simulated Geozone arrive/depart events
-
CalAmp
- LM-900
- LMU-1200
- LMU-2500
- etc.
- Receive data via UDP
- UDP acknowledgments
- Event-code to Status-code mapping
- GPIO simulated events
- Simulated Geozone arrive/depart events
- Estimated odometer calculation
- Accumulators (odometer, timers, 1-wire data, etc)
- Sending commands to the device via UDP or SMS (with available email to SMS gateway).
-
Digital Communications Technologies
Supported Features:
- Receive data via TCP/UDP ("REV" record type only)
- UDP acknowledgments
- Simulated Geozone arrive/depart events
- Estimated odometer calculation
-
Enfora
- MT-uL/GSM2238
- MT-Gu/GSM1218 (with Garmin FMI for driver communication)
- Mini-MT/GSM2228 (Personal Tracker)
- SA-G+/GSM1308
- Spider-AT
- Receive data via UDP
- UDP acknowledgments
- Garmin PND interface
- Garmin driver message to outbound email translation
- Optional headers
- ASCII/Binary mode
- PCELL information storage (binary-mode only)
- User-number to Status-code mapping
- GPIO simulated events
- Simulated Geozone arrive/depart events
- Estimated odometer calculation
- Sending commands to the device via UDP or SMS (with available email to SMS gateway)
- Comtrack J1708/J1939/OBDII interface (limited offer)
-
Falcom
- STEPIII (in development)
-
GlobalSat
- TR-102 (in development)
-
GlobalStar/Axonn SPOT
- SPOT (personal tracker)
- Satellite-based simplex communications
- Receive data via HTTP-based server
- Simulated Geozone arrive/depart events
- Estimated odometer calculation
-
GlobalStar/Axonn SmartONE
Supported Features:
- Satellite-based simplex communications
- Receive data via HTTP-based server
- Simulated Geozone arrive/depart events
- Estimated odometer calculation
-
Laipac
Supported Features:
- Receive data via TCP/UDP
- Simulated Geozone arrive/depart events
- Estimated odometer calculation
-
Meitrack
Supported Features:
- Receive data via TCP/UDP
- VT310 analog sensor inputs
- Fuel level sensor (provided by Meitrack)
- Simulated Geozone arrive/depart events
- Estimated odometer calculation
-
Oner Electronics Technology Limited
Supported Features:
- Receive data via TCP/UDP
- Analog sensors (fuel level monitors)
- Simulated Geozone arrive/depart events
- Estimated odometer calculation
- GPIO simulated events
-
SIMCom
- eLoc GL-100 (sold under the name "Spark Nano", "Enduro", etc) (personal tracker)
- Receive data via TCP/UDP
- Simulated Geozone arrive/depart events
- Estimated odometer calculation
- Sending commands to the device via UDP or SMS (with available email to SMS gateway)
-
Systems and Technology Corp.
Supported Features:
- Receive data via TCP
- Simulated Geozone arrive/depart events
- Estimated odometer calculation
-
Teltonika
Supported Features:
- Receive data via TCP/UDP
- Simulated Geozone arrive/depart events
- Estimated odometer calculation
-
Trimble
- TrimTrac
- TAIP - Trimble ASCII Interface Protocol
-
Wonde Proud
- SPT100 (personal tracker)
-
Xirgo
- XT-2000-G (in development)
- Simulated Geozone arrive/depart events
- Estimated odometer calculation
Feature Comparison Chart
The following chart compares the features available in the various available modules and add-ons.
(See Notes [#] below where indicated, for additional information)
| Feature | Open-Source OpenGTS |
Basic GTSEnterprise | Event Notification Rules Engine |
State-LineBorder Crossing |
| 1) General | ||||
| a) Web-based User Interface | Yes | Yes | -- | -- |
| b) Customizable Look-and-Feel | Yes | Yes | -- | -- |
| c) Geofence Arrive/Depart detection | Yes | Yes | -- | -- |
| d) "Events" Servlet for GoogleEarth KML Support | Yes | Yes | -- | -- |
| e) Access-Control-List (ACL) Support | Yes | Yes | -- | -- |
| f) International Support | Yes | Yes | -- | -- |
| g) Source Code Included | Yes | Yes | -- | -- |
| h) Secure Web-Access (SSL) | Yes [#1] | Yes [#1] | -- | -- |
| i) Server Auto Start on Reboot (Fedora) | -- | Yes | -- | -- |
| j) "Cron" based Task Server | -- | Yes | -- | -- |
| k) System "Offline" Support | -- | Yes | -- | -- |
| l) XML-based Web Service Support | -- | Yes | -- | -- |
| m) Database Management UI Tool | -- | Yes | -- | -- |
| 2) Device Communication Servers (DCS) | ||||
| a) "MotoDMTP" tracker for Motorola Phones | Yes | Yes | -- | -- |
| b) OpenDMTP compliant devices | Yes | Yes | -- | -- |
| h) Aspicore TC/UDP-based | Yes | Yes | -- | -- |
| i) Sanav HTTP-based server (GC-101/GX-101) | Yes | Yes | -- | -- |
| c) ICare TCP/UDP-based | Yes | Yes | -- | -- |
| d) Example 'Template' | Yes | Yes | -- | -- |
| e) "GPRMC" HTTP-based | Yes | Yes | -- | -- |
| f) "GPSMapper" HTTP-based server | Yes | Yes | -- | -- |
| g) "Mologogo" HTTP-based server | Yes | Yes | -- | -- |
| h) SIPGEAR UDP-based server | Yes | Yes | -- | -- |
| j) Sanav TCP/UDP-based server | -- | Yes | -- | -- |
| k) Other servers available | -- | Yes [#2] | -- | -- |
| l) Starter disable/enable | -- | Yes [#3] | -- | -- |
| l) Fuel Level Monitoring | -- | Yes [#3] | -- | -- |
| 3) Mapping | ||||
| a) Vehicle Location Map | Yes | Yes | -- | -- |
| b) Fleet/Group Location Map | Yes | Yes | -- | -- |
| c) Customizable Pushpins | Yes | Yes | -- | -- |
| d) Per Vehicle Pushpins on Fleet Map | Yes | Yes | -- | -- |
| e) Pushpin Info Balloons with Lat/Lon, Speed, Heading ,etc. | Yes | Yes | -- | -- |
| f) Selectable Map Providers | Yes | Yes | -- | -- |
| g) Date/Time Range Selection | Yes | Yes | -- | -- |
| h) Pushpins showing direction of travel | Yes | Yes | -- | -- |
| i) Pushpins showing device name label | Yes | Yes | -- | -- |
| j) Auto-Update | Yes | Yes | -- | -- |
| k) Replay vechicle travel | Yes | Yes | -- | -- |
| l) Export to Google Earth | Yes | Yes | -- | -- |
| m) Point-Radius Geozones | Yes | Yes | -- | -- |
| n) Polygon Geozones | Yes | Yes | -- | -- |
| o) Colorized Geozones | Yes | Yes | -- | -- |
| p) Display Geozones on Device/Fleet Map | Yes | Yes | -- | -- |
| 4) Reverse-Geocoding | ||||
| a) Confgurable Reverse-Geocoders | Yes | Yes | -- | -- |
| 5) Report Output Formats and Options | ||||
| a) HTML | Yes | Yes | -- | -- |
| b) CSV | Yes | Yes | -- | -- |
| c) XML | Yes | Yes | -- | -- |
| d) HTML - Sortable Table Columns | Yes | Yes | -- | -- |
| e) Email reports | Yes | Yes | -- | -- |
| 6) Vehicle Detail Reports | ||||
| a) Vehicle Event Detail | Yes | Yes | -- | -- |
| b) Vehicle Trip Report Detail | -- | Yes | -- | -- |
| c) Vehicle Geozone Elapsed Time Detail | -- | Yes | -- | -- |
| d) Vehicle Geozone/Driving Summary | -- | Yes | -- | -- |
| e) Vehicle Ignition-On Elapsed Time Detail | -- | Yes | -- | -- |
| f) Temperature Monitoring and Graphing | -- | Yes | -- | -- |
| 7) Fleet Detail Reports | ||||
| a) Vehicle Event Detail (by Group) | Yes | Yes | -- | -- |
| b) Vehicle Excess Speed (by Group) | Yes | Yes | -- | -- |
| c) Vehicle Trip Report Detail (by Group) | -- | Yes | -- | -- |
| d) Vehicle Geozone Detail (by Group) | -- | Yes | -- | -- |
| 8) Fleet Summary Reports | ||||
| a) Last Known Vehicle Location | Yes | Yes | -- | -- |
| b) Number of Received Events | Yes | Yes | -- | -- |
| c) PowerUp/Reboot Initialization | Yes | Yes | -- | -- |
| d) Ignition-On Elapsed Time Summary | -- | Yes | -- | -- |
| e) Session Connection Statistics | -- | Yes | -- | -- |
| f) Periodic Vehicle Maintenance | -- | Yes | -- | -- |
| g) Vehicle Distance Traveled | -- | Yes | -- | -- |
| h) User Login Audit | -- | Yes | -- | -- |
| i) Fuel Summary Report | -- | Yes [#3] | -- | -- |
| j) (SysAdmin) Unassigned Devices | -- | Yes | -- | -- |
| k) (SysAdmin) Account Last Login | -- | Yes | -- | -- |
| 9) Performance Reports | ||||
| a) Excess Speed | Yes | Yes | -- | -- |
| b) Driving/Stopped Time | Yes | Yes | -- | -- |
| 10) Administration Web-Interface | ||||
| a) Account Administration | Yes | Yes | -- | -- |
| b) User Administration | Yes | Yes | -- | -- |
| c) Device/Vehicle Administration | Yes | Yes | -- | -- |
| d) Group/Fleet Administration | Yes | Yes | -- | -- |
| e) Geozone Administration | Yes | Yes | -- | -- |
| f) Change Password | Yes | Yes | -- | -- |
| g) Role (ACL) Administration | -- | Yes | -- | -- |
| h) StatusCode Description Administration | -- | Yes | -- | -- |
| i) System Admin Account Manager | -- | Yes | -- | -- |
| j) System Admin System Info | -- | Yes | -- | -- |
| k) System Admin Find Assigned Mobile IDs | -- | Yes | -- | -- |
| 11) Rule-based Event Notification | ||||
| a) RulesEngine Event Notification | -- | Yes [#4] | Yes | -- |
| b) Send Emails on Event Triggers | -- | Yes [#4] | Yes | -- |
| c) Panic Button Notification | -- | Yes [#4] | Yes | -- |
| c) Geofence Arrive/Depart Notification | -- | Yes [#4] | Yes | -- |
| d) Selected Status Code Notification | -- | Yes [#4] | Yes | -- |
| e) Excessive Speed Notification | -- | Yes [#4] | Yes | -- |
| f) Exceeding Posted Speed Limit Notification | -- | -- | Yes [#5] | -- |
| g) Engine Fault Notification | -- | -- | Yes [#6] | -- |
| h) Full Rule Selector Definitions | -- | -- | Yes | -- |
| i) Event Notification Queue | -- | -- | Yes | -- |
| j) Event Notification Callback Support | -- | -- | Yes | -- |
| k) Rule Administration Web Interface | -- | -- | Yes | -- |
| m) Map Icon Selection based on Event Type | -- | -- | Yes | -- |
| m) GeoCorridor (route-based) geofencing | -- | -- | Yes | -- |
| 12) State Borderline-Crossing Detection | ||||
| a) State-Line Border Crossing Detection Database/Server | -- | -- | -- | Yes |
| b) State Border Crossing Summary Report | -- | -- | -- | Yes |
| c) State Mileage Summary Report | -- | -- | -- | Yes |
| 13) Supported Operating System Platforms | ||||
| a) Runs On Linux (Fedora 11 / 12 / 13 preferred) | Yes | Yes | Yes | Yes |
| b) Runs On FreeBSD | Yes | Yes | Yes | ? |
| b) Runs On OpenBSD | Yes | Yes | Yes | ? |
| c) Runs On Mac OS X | Yes | Yes | Yes | -- |
| d) Runs On Windows | Yes | Yes | Yes | -- |
| 14) Pricing and other Services | ||||
| a) Price | Free | (note 7) | (note 7) | (note 7) |
| b) Remote Installation Available (via ssh) | -- | (note 7) | (note 7) | (note 7) |
| d) Customization Services Available | -- | (note 7) | (note 7) | (note 7) |
|
Notes: 1 - Requires Tomcat SSL configuration. 2 - Other add-on servers available for additional fee. 3 - Depending on selected device commuication server add-on. 4 - Using "RuleFactoryLite" (hardcoded Java rules). 5 - Special Geonames/Navteq reverse-geocoder required. 6 - Special telematic hardware required. 7 - Contact us for details. |
||||
Other Supported Features
Here are few other additional custom features and modules we can provide for specific GPS tracking/telematic application requirements:
-
State-line border crossing detection:
For I.F.T.A. fuel tax reporting, supports detection of state border crossings (city, county/province, country, also possible with the proper shapefiles). Currently supports US states, however, with the proper shapefiles, other geographical areas could be supported as well. -
Support for trailer drop/hook detection:
(available only on selected client hardware). This feature provides reporting of which trailers are hooked to a truck, and where they were disconnected/dropped. Special hardware is required that can detect when a trailer has been atached, or detached, from the truck. -
Support for truck J1708
/ J1587
/ J1939
monitoring and engine disagnostics:
(available only on selected client hardware). Engine data buss monitoring allow collection of engine disagnostic information, such as actual vehicle odometer, RPM, fuel used, fault codes, etc. -
Support for load temperature monitoring:
(available only on selected client hardware). Temperature monitoring for refrigerated compartments, etc. -
Customized client telematic device integration:
Integration of features such as driver notification, Bluetooth/WiFi connectivity, specialized telematic data collection, legacy system integration, video system integration, tire pressure monitoring, etc. -
Additional commercial mapping provider and reverse-geocoding support:
Including MapTuit, MultiMap, ESRI, and others. -
Secure GeoCorridor support:
(available only on selected client hardware). For high-value loads, this provides route monitoring from one location to another. If the vehicle deviates from the route an alert event is sent, or if the vehicle dwells/stops too long in the route an alert event is sent. -
Support for other custom requirements:
We can help with the integration of the tracking/telematic data into legacy systems, or help with the development of other specific telematic requirements. -
Continuing upgrade support and maintenance:
We can provide continued upgrade support and maintenance to meet you specific requirements.
We can help you design a system that fits your specific requirements. Please contact us for additional information or assistance with your custom GPS tracking and telematic project. We have a team ready to assist you. Contact us at projects@geotelematic.com
|
